Product Details

Titanium Parts Properties

Our pure titanium tube, titanium alloy tube all follow ASTM B861, ASTM B862. Such as Ti-6Al-4V tube, Ti-0.2Pd Grade 7 tube, Ti-3Al-2.5V Grade 9 tube, Ti-15V-3Cr-3Sn-3Al tube.

Industrial Pure Titanium Parts Properties
Products Shape Condition δ or d/mm Room Temperature
σb/MPa σP0.2/Mpa δ5/% ψ/% α/(。) αKU/kJ·m-2 HBS
≥
Grade 1 Pie, ring Annealed S ≤ 100cm2 ≥ 280 170 30 35 - - -
Grade 2 ≥ 370 250 20 35 - - -
Grade 3 ≥ 440 320 18 35 - - -
Grade 4 ≥ 540 410 15 30 - - -
Grade 2 Free forging,
die forging		 Annealed m ≤ 60kg ≥ 310 - 20 45 - 490 d=4.7 - 5.2mm
Grade 3 ≥ 410 - 18 35 - 490 d=4.7 - 5.2mm
Grade 4 ≥ 510 - 13 30 - 490 d=4.7 - 5.2mm

Titanium Spare Parts

Specification: according to customer's requirements

Titanium Flanges

Specification: according to customer's requirements

Titanium Anode Baskets

Specification: non-standard, as per the customer's requirements
Technique: cutting, welding, bending
Standards: ASTM B381. ASTM B265
Material: Titanium Grade 1, Titanium Grade 2, Titanium Grade 5 ( 6Al-4V)
First: bath contamination, constant deposition
Second: uniform current distribution
Third: uniform anode area
Application: titanium basket for precious metal plating and hard chrome plating use

Titanium Forged Flanges

Material: Titanium Grade 1, Titanium Grade 2, Titanium Grade 5 ( 6Al-4V),
Specifications: ANSI/ASME B16.5, DIN 263x, BS 4504, HG/T 20592
Size: NPS 1/2 - NPS 24 (DN 15 - 600)
Pressure: 150# - 2500#, PN 2.5 - PN 160

Available Flange Types

  • Slip on flange
  • Welding neck flange
  • Threaded flange (screwed flange)
  • Plain flange
  • Blind flange (blank flange)
  • Lap Joint flange
  • Wocket welding flange
