  • Titanium alloys grade5 foil

Product Details

Ti-6Al-4V (Grade 5) Introduction

The main advantages of Ti-6Al-4V titanium alloy are excellent comprehensive performance and good technological characteristics. Ti-6Al-4V titanium alloy has a medium strength at room temperature and high temperature, good creep resistance and thermal stability, high performance and fatigue crack growth resistance of seawater, and satisfaction of salt stress corrosion fracture toughness and heat performance, sensitivity to the hydrogen is smaller than other alloys. Ti-6Al-4V titanium alloy has excellent process plasticity and superplasticity. It is suitable for the forming of various kinds of pressure machining methods, its welding and machining can be done in various ways.

α-β Type Titanium Alloy
Type Grade Chemical Composition Operating Temperature/˚C Intensity Level/MPa
α+β Grade 5 Ti - 6Al - 4V 400 ≥ 895
Ti-6Al-4V Alloy Properties
Shape Condition δ or d/mm Room Temperature 400˚C
σb/MPa σP0.2/Mpa δ5/% ψ/% α/(。) αKU/kJ·m-2 σb/MPa σ100/MPa
Sheet Annealed 0.8 - 2.0 ≥ 895 830 12 - - 35 590 540
2.1 - 5.0 ≥ 895 830 10 - - 30 590 540
5.1 - 10.0 ≥ 895 830 10 - - - 590 540
Sheet Annealed 0.8 - 4.0 925 - 1150 870 12 - - 35 590 540
4.1 - 5.0 925 - 1150 870 10 - - 30 590 540
5.1 - 10.0 895 - 1100 825 10 - - - 590 540
10.1 - 25.0 895 - 1100 825 9 - - - 590 540
Sheet Annealed 0.5 - 3.0 ≥ 925 870 12 - - 35 590 540
3.1 - 4.0 ≥ 925 870 10 - - 30 590 540
Wire Annealed 1.6 - 7.0 ≥ 895 - 10 - - - - -
Rod Annealed 8 - 90 ≥ 895 825 10 25 400 - 620 570
Rod Annealed ≤ 50 ≥ 930 860 10 25 400 - 590 570
51 - 70 ≥ 895 825 10 25 400 - 590 570
Rod Annealed 21 - 50 ≥ 930 860 10 25 - - 615 570
> 50 - 75 ≥ 895 825 10 25 - - 615 570
> 75 -100 ≥ 895 825 10 25 345 - 615 570
≥ 895 825 95 20 - - - -
>100-150 ≥ 895 825 10 25 295 - 600 600
≥ 895 825 9 20 - - - -
> 150 - 220 ≥ 895 825 10 20 - - - -
≥ 895 825 8 18 - - - -
Rod Annealed 21 - 100 ≥ 895 825 10 25 - - - -
> 100 - 150 ≥ 895 825 9 20 - - - -
> 150 - 220 ≥ 895 825 8 15 - - - -
Pie, Ring Annealed δ38 - 110 ≥ 895 825 10 25 - - - -
Rod, Wire Solution and aging 4.0 - 14.0 ≥ 1100 1000 10 20 - - - -
Pie, Casting Annealed s ≤100cm2 ≥ 895 825 10 25 - - - -
Pie, Ring Annealed δ38-110  m≤60kg ≥ 895 825 10 25 - - 612 570
Free forging,
Die forging
Annealed M ≤ 60kg ≥ 895 825 10 25 350 - 600 560
Plate forging Annealed M ≤ 60kg ≥ 890 825 10 30 345 - 620 570
m≤60-120kg ≥ 890 825 8 25 345 - 590 550
Plane forging Annealed δ ≤ 150 ≥ 895 825 10 30 350 - 600 560
≥ 895 825 10 25 - - - -
≥ 895 825 8 20 - - - -
δ ≤ 50 ≥ 930 860 10 30 350 - 600 560
≥ 930 860 10 25 - - - -
Ring forging Annealed  m ≤ 60kg ≥ 895 825 10 25 345 - 615 570
Ti-6Al-4V Alloy Chemical Composition (wt)%
Grade Element Impurity ≤
Al V Ti Fe C H O Other Elements
Single Total
Grade 5 5.5 - 6.8 3.5 - 4.5 Balance 0.30 0.10 0.015 0.20 0.10 0.40

Ti-6Al-4V (Grade 5) Application

The main semi-finished form of Ti-6Al-4V titanium alloy is titanium rod, forging, titanium sheet, titanium plate, profile and titanium wire, etc., also can be used for casting. The alloy is mainly used in annealing, and it can be strengthened with a certain degree of solidification aging treatment. However, the quenching cross section is generally no more than 25 to 30mm. It is suitable for manufacturing various parts that work within the wide temperature range from -196-450˚C, especially the parts designed with damage tolerance principle. Ti-6Al-4V titanium alloy has been widely used in aerospace industry and civil industry. The production of Ti-6Al-4V alloy semi-finished products of the world accounts for more than half of the total output of all titanium alloy semi-finished products, and more than 80% in the aerospace industry.
Ti-6Al-4V(Grade 5) Application
Ti-6Al-4V Application on Boeing 777
Product Condition σn/MPa Shape
Ti-6Al-4V Annealed 895 All forms
β Annealed 895 forged piece
STA 1100 fastener
