Ti-15V-3Cr-3Sn-3Al

  • Ti 15333 alloy
  • Titanium alloy 15v-3cr-35n-3al

Product Details

Ti-15V-3Cr-3Sn-3Al Introduction

Ti-15V-3Cr-3Sn-3Al alloy is a kind of stable β-type titanium alloy. The alloy has excellent cold rolling and cold forming property. The alloy also has excellent welding performance and corrosion resistance. TB5 alloy is mainly used to manufacture various kinds of sheet metal components, and also can manufacture fasteners. It can meet the requirements of improving structural efficiency, high production efficiency and low manufacturing cost. The main semi-finished products of the alloy are titanium sheet, titanium strip and titanium rod, and also can produce titanium pipe fittings and castings.

α-β Type Titanium Alloy Properties
Type Grade Chemical Composition Operating Temperature/˚C Intensity Level/MPa Application
near β Ti-15-3 Ti-15V-3Cr-3Sn-3Al 290 ≥ 1080

With excellent cold forming properties, it can form medium and complex sheet metal parts at room temperature. It can also be superplastic in the above 700 degree, welding performance is excellent. Suitable for making aerospace sheet metal parts and fasteners

Ti-15V-3Cr-3Sn-3Al Alloy Properties
Shape δ or d/mm Condition Room Temperature
σb/MPa σP0.2/MPa δ5/% δ50/% ψ/% α/(。) τ/Mpa
Sheet,Plate ≤ 3.0 solution treatment 705-945 690-870 ≥ 12 - - ≥ 105 -
ST+540˚C,8h, air cooling ≥ 1000 ≥ 965 ≥ 7 - - - -
ST+520˚C,8h, air cooling ≥ 1080 ≥1010 ≥ 6 - - - -
ST+480˚C,8h, air cooling ≥ 1240 ≥1170 ≥ 5 - - - -
Rod,Wire 2.5-6.5 solutio treatment 705-945 - - ≥ 15 ≥ 60 - ≥ 550
ST+540˚C,8h, air cooling ≥ 1000 ≥ 965 - ≥ 10 ≥ 25 - ≥ 650
ST+520˚C,8h, air cooling ≥ 1080 ≥ 1010 - ≥ 8 ≥ 20 - ≥ 700
Ti-3Al-2.5V Heat Distortion Process Specification
Heat Distortion Type Heat Temperature/˚C Final Temperature/˚C Fire Deformation/%
ingot formation 1000-1050 ≥ 850 30-60
billet forging 950-1050 ≥ 800 40-60
slap breakdown 1000-1050 ≥ 800 40-60
sheet rolling 900-950 ≥ 800 40-60
rod rolling 800-900 ≥ 750 50-80
rod (wire) rotary swaging 700-740 ≥ 600 10-20

Ti-15V-3Cr-3Sn-3Al Application

Ti-15V-3Cr-3Sn-3Al titanium alloy is mainly used in the manufacture of high strength sheet metal parts in aircraft structure and rivets for cold riveting. It has been used in the manufacture of aircraft resistance umbrella beams and matching rivets. In the satellite structure, it is used to make distant engine supports and cones. On the civilian field, it has been used to make golf heads.
Ti-15V-3Cr-3Sn-3Al Application
Ti Alloy Application On Boeing 777 Airplane
Grade Status σn/MPa Shape
Ti-15V-3Cr-3Al-3Sn STA 1035 Sheet
STA 1140 Casting
