Zirconium Target

  • Zirconium target
  • Zirconium targets

Product Details

Zirconium Target Introduction

Zirconium Sputtering Target
Normal material: R60702 R60705
Special material:
High purity zirconium target by French imports of iodinated zirconium stick by electronic bombardment furnace is melting, forging, machine add becomes. Its zirconium content can reach 99.95%.
Specification:
Cylindrical target: Dia 58 mm x T 30 mm, Dia 100 mm x T 40 mm, Dia 85 mm x T 45 mm etc.
Board target: 8 mm x 170 mm x 300 mm, 14 mm x 150 mm x 500 mm, 6 mm x 125 mm x 500 mm etc.
Tube target: OD 148 mm x WT 11. 5 mm x L 686mm, OD 88 mm x WT 10 mm x L 1230 mm etc.

Non-nuclear Industrial Zirconium Target Chemical Composition
Products Chemical Composition (wt%) ≤ Standard
Zr+Hf ≥ Hf Fe+Cr Sn H N C Nb O
R60700 99.2 4.5 0.20 (max) - 0.005 0.025 0.05 - 0.10 ASTM B551/551M
R60702 99.2 4.5 0.20 (max) - 0.005 0.025 0.05 - 0.16
R60704 97.5 4.5 0.20 - 0.40 1.0-2.0 0.005 0.025 0.05 - 0.18
R60705 95.5 4.5 0.20 (max) - 0.005 0.025 0.05 2.0 - 3.0 0.18
R60706 95.5 4.5 0.20 (max) - 0.005 0.025 0.05 2.0 - 3.0 0.16

If you need any assistance, please contact us.
